Part diagram LINKAGE BF6L513R - CRAWLER EXCAVATORS Case 170B (CASE CRAWLER EXCAVATOR (S/N 1501-) (S/N 12501-) (EUROPE) (2/87-12/89)) | 777parts.com
# Part No. Description Qty
C4439301 C4***01 HANDWHEEL 1
D4339344 D4***44 SLEWING RING 1
C3533009 C3***09 SCREW 8
E2745445 E2***45 BLOCK; 2.75mm
F2745446 F2***46 BLOCK; SPARE PART 2.60mm
G2745447 G2***47 BLOCK; SPARE PART 2.45mm
H2745448 H2***48 BLOCK; SPARE PART 2.30mm
J2745449 J2***49 BLOCK; SPARE PART 2.90mm
K2745450 K2***50 BLOCK; SPARE PART 3.05mm
S3743220 S3***20 SLEEVE 6
L4528756 L4***56 BUSHING; 0.50mm
K4528755 K4***55 BUSHING; 0.70mm
X7546068 X7***68 BUSHING; 1.00mm
K6146069 K6***69 SEALING RING; SEALRING 6
U0136201 U1***01 RING, SNAP; RING SNAP 12
P1229294 P1***94 PISTON PIN 6
D3743207 D3***07 PISTON 6
R3743219 R3***19 BEARING LINER 6
L2143288 L2***88 CRANKSHAFT 1
T3749638 T3***38 KIT 6
M4942757 M4***57 ROD, CONNECTING 6
U2527879 U2***79 DOWEL 6
M1933805 M1***05 SCREW 12
S0036057 S3***57 SPLIT PIN/SAFETY PIN; SPARE PART 1
C0435714 C4***14 SPLIT PIN/SAFETY PIN 1
U0036059 U3***59 SPLIT PIN/SAFETY PIN 1
D6946049 D6***49 GASKET 1
X3939323 X3***23 WHEEL 1
N0036099 N3***99 SPLIT PIN/SAFETY PIN 1
J7946278 J7***78 SHOCK ABSORBER 1
K0238588 K2***88 PULLEY 1
K1933803 K1***03 SCREW 6
X2545408 X2***08 WASHER; SPARE PART 6
