Case 170FG (POCLAIN EXCAVATOR W/ELECTRIC MOTOR (75KW 380V) (1/85-12/92))

CRAWLER EXCAVATORS Case 170FG
/case/170FG/m85/s-238.html / No Description / WINDSHIELD

Select section

Subsection

Unit

Part diagram WINDSHIELD - CRAWLER EXCAVATORS Case 170FG (POCLAIN EXCAVATOR W/ELECTRIC MOTOR (75KW 380V) (1/85-12/92)) | 777parts.com
# Part No. Description Qty
W4***99 LEVER 1
XX***XX 1
W2***99 SELF LUB RING 2
B3***20 SPLIT PIN/SAFETY PIN 1
T7***75 CLEVIS 1
S5***97 PIN 1
V1***67 PIN 1
V5***51 CLEVIS 1
J1***36 PIN 1
A1***33 BEARING; C|CASE : STOP - PART NOT LONGER AVAILABLE ....... 1 NLS POCLAIN : BEARING - ORDER THE REFERENCE ....... 1 203066C92 1
E7***43 COMPRESSION SPRING,Compression, 11.4mm OD x 64mm L 1
X8***79 CYLINDER END CAP 1
V1***67 PIN 1
F4***01 LEVER 1
XX***XX 1
W2***99 SELF LUB RING 2
NLS NO LONGER SERVICED 1
E7***43 COMPRESSION SPRING,Compression, 11.4mm OD x 64mm L 1
J1***36 PIN 1
V5***51 CLEVIS 1
T7***75 CLEVIS 1
S5***97 PIN 1
B3***20 SPLIT PIN/SAFETY PIN 1
W8***78 SUPPORT 1
XX***XX 1
L2***87 NUT 8
L8***08 SEAL,4504mm L 1
B1***88 WINDSHIELD 1
Z8***31 SEAL,2243mm L
J7***38 WASHER 3
12***04 BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8 3
F2***30 SUPPORT 1
J7***38 WASHER 2
12***04 BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8 2
12***04 BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8 3
J7***38 WASHER 3
A1***33 BEARING; C|CASE : STOP - PART NOT LONGER AVAILABLE ....... 1 NLS POCLAIN : BEARING - ORDER THE REFERENCE ....... 1 203066C92 2
