| 1 |
12***00 |
BOLT,M6 x 20mm, Cl 8.8; If Used |
2 |
| 1 |
86***26 |
BOLT,Hex, M6 x 12mm, Cl 8.8 |
2 |
| 2 |
86***28 |
LOCK WASHER,6.1mm ID x 11.8mm OD x 1.7mm Thk |
2 |
| 3 |
87***62 |
BRACKET; Throttle Rod Bracket; No Longer Used, Order Ref 31, 87051143 |
1 |
| 4 |
88***98 |
JAM NUT,Jam, 1/4"-28, G2 |
1 |
| 5 |
80***82 |
LOCK WASHER,1/4" |
1 |
| 6 |
87***18 |
THREADED ROD; Throttle Rod; Replaces 87688638; If Used |
1 |
| 6 |
87***22 |
ROD; Throttle Rod |
1 |
| 7 |
87***24 |
CLAMP,11.1mm, Coat, 10.3mm Bolt Hole, P Type |
2 |
| 8 |
69***71 |
SPACER,9.77mm ID x 15.87mm OD x 5.03mm Thk |
2 |
| 9 |
A1***36 |
KNOB |
1 |
| 10 |
H1***20 |
BALL JOINT |
3 |
| 11 |
87***73 |
THROTTLE CONTROL; Hand Throttle |
1 |
| 12 |
13***C1 |
DISC |
1 |
| 13 |
R1***71 |
WASHER |
1 |
| 14 |
86***56 |
WASHER,13.3mm ID x 28.5mm OD x 4mm Thk |
2 |
| 15 |
87***76 |
THROTTLE CONTROL; Throttle Control |
1 |
| 16 |
86***09 |
NUT,1/4"-28, G5 |
2 |
| 17 |
18***A2 |
SLEEVE |
1 |
| 18 |
18***A1 |
BUSHING; Throttle Bushing |
1 |
| 19 |
87***95 |
SLEEVE; Throttle Pivot |
1 |
| 20 |
87***39 |
TORSION SPRING |
1 |
| 21 |
87***49 |
BOLT,Hex, M12 x 60mm, Cl 10.9; Bolt, M12 X 60 10.9 |
1 |
| 22 |
86***64 |
JAM NUT,Jam, 1/4"-28, G5 |
3 |
| 23 |
87***94 |
ROD; Throttle Rod, Foot |
1 |
| 24 |
D1***83 |
COTTER PIN,1.04mm OD x 21.4mm L, Ring |
1 |
| 25 |
86***13 |
WASHER,9mm ID x 24mm OD x 2mm Thk |
1 |
| 26 |
16***21 |
BOLT,M8 x 1.25 x 55mm, Cl 8.8 |
1 |
| 27 |
87***77 |
PEDAL; Foot Pedal; Replaces 87650090 |
1 |
| 28 |
32***A1 |
PAD; Foot Pedal Pad |
1 |
| 29 |
43***17 |
SCREW,Hex, M6 x 1.0 x 30mm, Cl 8.8; ` |
1 |
| 30 |
22***A1 |
SQUARE NUT,M8 x 1.25, Cl 8 |
1 |
| 31 |
87***43 |
ROD ASSY.; If Used |
1 |
| 31 |
87***21 |
BRACKET; Throttle Bracket |
1 |
| 32 |
88***98 |
JAM NUT,Jam, 1/4"-28, G2 |
1 |
| 33 |
80***82 |
LOCK WASHER,1/4" |
1 |
| 34 |
12***00 |
BOLT,M6 x 20mm, Cl 8.8; If Used |
2 |
| 34 |
86***26 |
BOLT,Hex, M6 x 12mm, Cl 8.8 |
2 |
| 35 |
86***28 |
LOCK WASHER,6.1mm ID x 11.8mm OD x 1.7mm Thk |
1 |
| 36 |
86***36 |
CLAMP,12.7mm, Coat, 8.7mm Bolt Hole, P Type |
1 |
| 37 |
86***68 |
SERRATED NUT,Hex, M8 x 1.25, Cl 8 |
1 |
| 38 |
12***04 |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8 |
1 |
| 38 |
43***28 |
BOLT,M8 x 1.25 x 30mm, Cl 8.8 |
1 |
| 39 |
86***50 |
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk |
1 |
| 40 |
87***59 |
SPACER,13.10mm ID x 15.90mm OD x 6.4mm L; Spacer Door Lock |
1 |
| 41 |
86***84 |
WASHER,9mm ID x 16mm OD x 1.6mm Thk |
1 |
